APT1608SECK

Kingbright
RoHS
RoHS RoHS compliant
Package 0603 (1608 Metric)
Category Optoelectronics / LED Indication - Discrete
Description LED ORANGE CLEAR CHIP SMD
PDF
/
Buying Options
Total Price: USD $0.26
Unit Price: USD $0.2552
≥1 USD $0.2552
≥10 USD $0.2024
≥100 USD $0.090904
≥500 USD $0.082122
≥1000 USD $0.067461
Inventory: 48480
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 12 Weeks

Physical

Mount Surface Mount
Mounting Type Surface Mount
Package / Case 0603 (1608 Metric)
Number of Pins 2
Shape RECTANGULAR

Technical

Packaging Tape & Reel (TR)
Published 2009
Size / Dimension 1.60mm Lx0.80mm W
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 2
ECCN Code EAR99
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Color Orange
Packing Method TAPE AND REEL
Number of Functions 1
Case Code (Metric) 1608
Case Code (Imperial) 0603
Configuration Standard
Voltage - Forward (Vf) (Typ) 2.1V
Viewing Angle 120°
Optoelectronic Device Type SINGLE COLOR LED
Forward Current 20mA
Lens Style Rectangle with Flat Top
Lens Size 1.20mmx0.80mm
Luminous Intensity 240 mcd
Millicandela Rating 180mcd
Lens Transparency Clear
Wavelength - Peak 610nm
Lens Color Colorless
Wavelength - Dominant 601nm
Number of LEDs 1

Dimensions

Height 750μm

Compliance

RoHS Status ROHS3 Compliant
Lead Free Lead Free
