AA3021SESK
RoHS
RoHS compliant
RoHS compliantPackage 2-SMD, J-Lead
Category Optoelectronics / LED Indication - Discrete
Description
LED ORANGE RECT CLEAR SMD
PDF
/
Buying Options
Total Price: USD $0.35
Unit Price: USD $0.352
≥1 USD $0.352
≥10 USD $0.21648
≥100 USD $0.124696
≥500 USD $0.097592
Inventory: 1373
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Height 1.3mm
Technical
Wavelength - Dominant 601nm
Lens Color Colorless
Wavelength - Peak 610nm
Lens Transparency Clear
Millicandela Rating 300mcd
Luminous Intensity 400 mcd
Lens Size 2.50mmx1.50mm
Lens Style Oval with Flat Top
Forward Current 20mA
Optoelectronic Device Type SINGLE COLOR LED
Viewing Angle 125°
Voltage - Forward (Vf) (Typ) 2.1V
Configuration Standard
Terminal Pitch 2.8mm
Number of Functions 1
Packing Method TAPE AND REEL 7"
Power Rating 75mW
HTS Code 8541.40.20.00
Color Orange
Min Operating Temperature -40°C
Max Operating Temperature 85°C
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Size / Dimension 2.70mm Lx2.00mm W
Published 2011
Packaging Cut Tape (CT)
Physical
Shape RECTANGULAR
Package / Case 2-SMD, J-Lead
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 12 Weeks
