QTLP630CBTR
RoHS
RoHS compliant
RoHS compliantPackage 0805 (2012 Metric)
Category Optoelectronics / LED Indication - Discrete
Description
LED Uni-Color Blue 430nm 2-Pin Chip 0805(2012Metric) T/R
PDF
/
Inventory: 1122
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Height 1.2mm
Technical
Wavelength - Dominant 465nm
Reverse Voltage 5V
Lens Color Colorless
Wavelength - Peak 430nm
Lens Transparency Clear
Millicandela Rating 20mcd
Luminous Intensity 20 mcd
Lens Size 1.40mmx1.25mm
Lens Style Rectangle with Flat Top
Forward Current 20mA
Optoelectronic Device Type SINGLE COLOR LED
Viewing Angle 140°
Voltage - Forward (Vf) (Typ) 3.8V
Power Dissipation 135mW
Configuration Standard
Number of Elements 1
Depth 1.45mm
Number of Functions 1
Packing Method TAPE AND REEL 7"
Subcategory Visible LEDs
Color Blue
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Number of Terminations 2
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Pbfree Code yes
Size / Dimension 2.00mm Lx1.25mm W
Published 2002
Packaging Tape & Reel (TR)
Physical
Shape RECTANGULAR
Number of Pins 2
Package / Case 0805 (2012 Metric)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 12 Weeks
