5988450202CF
RoHS
RoHS compliant
RoHS compliantPackage 0606 (1616 Metric)
Category Optoelectronics / LED Indication - Discrete
Description
LED GREEN/YELLOW CLEAR SMD
PDF
/
Inventory: 1410
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mounting Type Surface Mount
Package / Case 0606 (1616 Metric)
Surface Mount YES
Shape RECTANGULAR
Technical
Packaging Strip
Published 2013
Series 598
Size / Dimension 1.60mm Lx1.60mm W
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 4
Color Green, Yellow
Additional Feature UL RECOGNIZED
HTS Code 8541.40.20.00
Packing Method TAPE
Number of Functions 1
Terminal Pitch 1.4mm
Operating Temperature (Max) 100°C
Operating Temperature (Min) -40°C
Configuration SEPARATE, 2 ELEMENTS
Voltage - Forward (Vf) (Typ) 3.2V Green 2V Yellow
Viewing Angle 140°
Optoelectronic Device Type DUAL COLOR LED
Current - Test 20mA Green 20mA Yellow
Lens Style Rectangle with Flat Top
Lens Size 1.10mmx0.90mm
Millicandela Rating 120mcd Green, 120mcd Yellow
Lens Transparency Clear
Lens Color Colorless
Forward Current-Max 0.02A
Overall Height 0.7mm
Wavelength - Dominant 530nm Green 592nm Yellow
Dimensions
Height (Max) 0.70mm
Compliance
RoHS Status ROHS3 Compliant
