5988430207CF
RoHS
RoHS compliant
RoHS compliantPackage 0606 (1616 Metric)
Category Optoelectronics / LED Indication - Discrete
Description
LED GREEN/ORANGE CLEAR SMD
PDF
/
Inventory: 3380
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Height (Max) 0.70mm
Technical
Wavelength - Dominant 568nm Green 605nm Orange
Overall Height 0.7mm
Forward Current-Max 0.02A
Lens Color Colorless
Lens Transparency Clear
Millicandela Rating 40mcd Green, 100mcd Orange
Lens Size 1.10mmx0.90mm
Lens Style Rectangle with Flat Top
Current - Test 20mA Green 20mA Orange
Optoelectronic Device Type DUAL COLOR LED
Viewing Angle 140°
Voltage - Forward (Vf) (Typ) 2V Green 2V Orange
Configuration SEPARATE, 2 ELEMENTS
Operating Temperature (Min) -40°C
Operating Temperature (Max) 100°C
Reach Compliance Code compliant
Terminal Pitch 1.4mm
Number of Functions 1
Packing Method TAPE AND REEL 7"
HTS Code 8541.40.20.00
Additional Feature UL RECOGNIZED
Color Green, Orange
Number of Terminations 4
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
Size / Dimension 1.60mm Lx1.60mm W
Series 598
Published 2013
Packaging Tape & Reel (TR)
Physical
Shape RECTANGULAR
Surface Mount YES
Package / Case 0606 (1616 Metric)
Mounting Type Surface Mount
