5975312407NF
RoHS
RoHS compliant
RoHS compliantPackage 0603 (1608 Metric)
Category Optoelectronics / LED Indication - Discrete
Description
LED GREEN DIFFUSED 2SMD
PDF
/
Buying Options
Total Price: USD $0.55
Unit Price: USD $0.553023
≥1 USD $0.553023
≥10 USD $0.52172
≥100 USD $0.492186
≥500 USD $0.464321
≥1000 USD $0.438047
Inventory: 1172
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mounting Type Surface Mount
Package / Case 0603 (1608 Metric)
Surface Mount YES
Shape RECTANGULAR
Technical
Packaging Tape & Reel (TR)
Published 2014
Series 597
Size / Dimension 1.60mm Lx0.80mm W
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 2
Terminal Finish Matte Tin (Sn) - with Nickel (Ni) barrier
Color Green
HTS Code 8541.40.20.00
Subcategory Visible LEDs
Packing Method TAPE AND REEL 7"
Number of Functions 1
Terminal Pitch 1.6mm
Operating Temperature (Max) 100°C
Operating Temperature (Min) -40°C
Configuration Standard
Voltage - Forward (Vf) (Typ) 2.1V
Viewing Angle 152°
Optoelectronic Device Type SINGLE COLOR LED
Current - Test 20mA
Lens Style Rectangle with Flat Top
Lens Size 1.10mmx0.80mm
Luminous Intensity 9.8 mcd
Millicandela Rating 9.8mcd
Lens Transparency Diffused
Wavelength - Peak 560nm
Lens Color White
Forward Current-Max 0.03A
Forward Voltage-Max 2.8V
Overall Height 0.7mm
Wavelength - Dominant 567nm
Luminous Intensity-Min 152 cd
Dimensions
Height (Max) 0.70mm
Compliance
RoHS Status ROHS3 Compliant
