5219768F
RoHS
RoHS compliant
RoHS compliantPackage Radial
Category Optoelectronics / LED Indication - Discrete
Description
LED RED/YELLOW DIFFUSED 3MM T/H
PDF
/
Buying Options
Total Price: USD $0.91
Unit Price: USD $0.9064
≥1 USD $0.9064
≥10 USD $0.57112
≥100 USD $0.422576
≥500 USD $0.319792
≥1000 USD $0.296947
≥3000 USD $0.290092
Inventory: 2165
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mounting Type Through Hole
Package / Case Radial
Surface Mount NO
Technical
Packaging Bulk
Published 2010
Series 521
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Terminal Finish Copper/Nickel/Silver (Cu/Ni/Ag)
Color Red, Yellow
HTS Code 8541.40.20.00
Subcategory Visible LEDs
Number of Functions 1
Terminal Pitch 2.54mm
Operating Temperature (Max) 100°C
Operating Temperature (Min) -55°C
Configuration Bidirectional
Voltage - Forward (Vf) (Typ) 2V Red 2.1V Yellow
Viewing Angle 80°
Optoelectronic Device Type DUAL COLOR LED
Current - Test 20mA Red 20mA Yellow
Lens Style Round with Domed Top
Lens Size 3.00mm Dia
Luminous Intensity 5.6 mcd
Millicandela Rating 5.6mcd Red, 5.6mcd Yellow
Lens Transparency Diffused
Wavelength - Peak 630nm Red 585nm Yellow
Lens Color White
Forward Current-Max 0.03A
Forward Voltage-Max 2.8V
Overall Height 4.44mm
T-code T-1
Dimensions
Height (Max) 5.70mm
Compliance
RoHS Status ROHS3 Compliant
