CLM1B-AKW-CUAVB253
RoHS
RoHS compliant
RoHS compliantPackage 2-PLCC
Category Optoelectronics / LED Indication - Discrete
Description
Standard LEDs - SMD Amber LED
PDF
/
Buying Options
Total Price: USD $0.17
Unit Price: USD $0.1672
≥1 USD $0.1672
≥10 USD $0.154
≥100 USD $0.142296
≥500 USD $0.127266
Inventory: 3215
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Height 2.05mm
Technical
Wavelength - Dominant 591nm
Reverse Voltage 5V
Lens Color White
Lens Transparency Diffused
Illumination Color Orange
Luminous Intensity 785 mcd
Lens Style Round with Flat Top
Forward Current 20mA
Optoelectronic Device Type SINGLE COLOR LED
Viewing Angle 120°
Voltage - Forward (Vf) (Typ) 2.1V
Power Dissipation 130mW
Configuration Standard
Number of Elements 1
Base Part Number CLM1B
Depth 2.7mm
Number of Functions 1
Packing Method TAPE AND REEL 7"
Additional Feature HIGH RELIABILITY
Color Amber
Min Operating Temperature -40°C
Max Operating Temperature 100°C
Number of Terminations 2
Moisture Sensitivity Level (MSL) 5A (24 Hours)
Part Status Active
Size / Dimension 3.20mm Lx2.70mm W
Packaging Tape & Reel (TR)
Physical
Number of Pins 2
Package / Case 2-PLCC
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 7 Weeks
