5530132
RoHS
RoHS compliant
RoHS compliantPackage /
Category Optoelectronics / LEDs - Circuit Board Indicators, Arrays, Light Bars, Bar Graphs
Description
LED 2HI 3MM YEL OVER GREEN PC MN
PDF
/
Inventory: 3007
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Technical
Luminous Intensity-Min 0.0022 cd
T-code T-1
Number of LEDs 2
Overall Height 9.65mm
Forward Voltage-Max 3V
Wavelength - Peak 563nm 585nm
Millicandela Rating 16mcd Green, 6.3mcd Yellow
Lens Type Diffused, Tinted
Luminous Intensity 6.3/16.0 mcd
Lens Size 3mm T-1
Lens Style Round with Domed Top
Optoelectronic Device Type DUAL COLOR LED ARRAY
Viewing Angle 45°
Current 10mA
Configuration 2 High
Operating Temperature (Min) -25°C
Operating Temperature (Max) 85°C
Reach Compliance Code compliant
Terminal Pitch 2.54mm
Number of Functions 2
Packing Method BAG
Subcategory Other Optoelectronics
HTS Code 8541.40.20.00
Additional Feature HIGH RELIABILITY
Voltage - Rated 2.1V
Color Green (x 1), Yellow (x 1)
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
Number of Terminations 4
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e1
Series 553
Published 2001
Packaging Bulk
Physical
Mounting Feature RADIAL MOUNT
Surface Mount NO
Mounting Type Through Hole, Right Angle
