HSMM-C170
RoHS
RoHS compliant
RoHS compliantPackage 0805 (2012 Metric)
Category Optoelectronics / LED Indication - Discrete
Description
LED Uni-Color Green 523nm 2-Pin Chip LED T/R
PDF
/
Buying Options
Total Price: USD $1.23
Unit Price: USD $1.232
≥1 USD $1.232
≥10 USD $0.77968
≥100 USD $0.577104
≥500 USD $0.530341
≥1000 USD $0.436753
≥3000 USD $0.41492
Inventory: 1820
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Height 800μm
Technical
Wavelength - Dominant 525nm
Forward Voltage-Max 3.9V
Reverse Voltage 5V
Luminous Flux 490 lm
Lens Color White
Wavelength - Peak 523nm
Lens Transparency Diffused
Luminous Intensity 120 mcd
Lens Size 1.40mmx1.25mm
Lens Style Rectangle with Flat Top
Forward Current 20mA
Optoelectronic Device Type SINGLE COLOR LED
Viewing Angle 170°
Voltage - Forward (Vf) (Typ) 3.3V
Power Dissipation 78mW
Configuration Standard
Number of Elements 1
Case Code (Imperial) 0805
Case Code (Metric) 2012
Base Part Number HSMM-C170
Depth 1.25mm
Number of Functions 1
Packing Method TAPE AND REEL 7"
Power Rating 78mW
Subcategory Visible LEDs
Color Green
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Terminal Finish Gold (Au) - with Nickel (Ni) barrier
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 2A (4 Weeks)
Part Status Active
JESD-609 Code e4
Size / Dimension 2.00mm Lx1.25mm W
Published 2010
Packaging Tape & Reel (TR)
Physical
Shape RECTANGULAR
Number of Pins 2
Package / Case 0805 (2012 Metric)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 9 Weeks
