HSMJ-A401-T40M1
RoHS
RoHS compliant
RoHS compliantPackage 4-PLCC
Category Optoelectronics / LED Indication - Discrete
Description
BROADCOM LIMITED HSMJ-A401-T40M1 LED, Red Orange, SMD, 50 mA, 2.2 V, 615 nm
PDF
/
Buying Options
Total Price: USD $0.6
Unit Price: USD $0.5984
≥1 USD $0.5984
≥10 USD $0.39248
≥100 USD $0.256872
≥500 USD $0.202778
Inventory: 19875
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Height 2.1mm
Technical
Reverse Voltage-Max 5V
Number of LEDs 1
Wavelength - Dominant 615nm
Forward Voltage-Max 2.5V
Lens Color Colorless
Wavelength - Peak 621nm
Lens Transparency Clear
Illumination Color Orange
Millicandela Rating 500mcd
Luminous Intensity 715 mcd
Lens Size 2.20mm Dia
Lens Style Round with Flat Top
Forward Current 50mA
Optoelectronic Device Type SINGLE COLOR LED
Viewing Angle 120°
Voltage - Forward (Vf) (Typ) 2.2V
Power Dissipation 180mW
Configuration Standard
Base Part Number HSMJ-A401
Terminal Pitch 3mm
Number of Functions 1
Packing Method TAPE AND REEL 7"
Power Rating 180mW
Subcategory Visible LEDs
Color Red
Min Operating Temperature -40°C
Max Operating Temperature 100°C
Terminal Finish Pure Tin (Sn)
ECCN Code EAR99
Number of Terminations 4
Moisture Sensitivity Level (MSL) 2A (4 Weeks)
Part Status Active
Size / Dimension 3.20mm Lx2.80mm W
Published 2007
Packaging Tape & Reel (TR)
Physical
Number of Pins 4
Package / Case 4-PLCC
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 18 Weeks
