XZCWD81FS
RoHS
RoHS compliant
RoHS compliantPackage 2-SMD, J-Lead
Category Optoelectronics / LED Indication - Discrete
Description
LED 1103 RA WHITE WATER CLEAR
PDF
/
Inventory: 3313
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height (Max) 0.80mm
Technical
Overall Height 0.8mm
Forward Current-Max 0.03A
Lens Color Colorless
Lens Transparency Clear
Millicandela Rating 497mcd
Luminous Intensity 297.0 mcd
Lens Size 2.30mmx0.57mm
Lens Style Rectangle with Flat Top
Current - Test 20mA
Optoelectronic Device Type SINGLE COLOR LED
Viewing Angle 110°
Voltage - Forward (Vf) (Typ) 3.3V
Configuration SINGLE
Operating Temperature (Min) -40°C
Operating Temperature (Max) 85°C
Terminal Pitch 2.4mm
Number of Functions 1
Packing Method TAPE AND REEL
HTS Code 8541.40.20.00
Color White
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Pbfree Code yes
Size / Dimension 2.50mm Lx1.20mm W
Published 2014
Packaging Tape & Reel (TR)
Physical
Shape RECTANGULAR
Surface Mount YES
Package / Case 2-SMD, J-Lead
Mounting Type Surface Mount, Right Angle
