HSMF-C155
RoHS
RoHS compliant
RoHS compliantPackage 1210 (3225 Metric)
Category Optoelectronics / LED Indication - Discrete
Description
LED GREEN/RED DIFFUSED CHIP SMD
PDF
/
Buying Options
Total Price: USD $0.23
Unit Price: USD $0.22895
≥1 USD $0.22895
≥10 USD $0.1881
≥100 USD $0.18145
≥500 USD $0.17575
≥1000 USD $0.17005
≥3000 USD $0.15295
Inventory: 23491
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 9 Weeks
Physical
Contact Plating Gold
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 1210 (3225 Metric)
Number of Pins 4
Shape RECTANGULAR
Technical
Packaging Tape & Reel (TR)
Published 2010
Size / Dimension 3.20mm Lx2.70mm W
JESD-609 Code e4
Part Status Active
Moisture Sensitivity Level (MSL) 2A (4 Weeks)
Number of Terminations 4
ECCN Code EAR99
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Color Green, Red
Additional Feature SUPPORTS INFRARED
Subcategory Visible LEDs
Power Rating 65mW
Voltage - Rated DC 1.1V
Packing Method TR, 7 INCH
Max Power Dissipation 65mW
Number of Functions 2
Terminal Pitch 3.5mm
Depth 3.2mm
Base Part Number HSMF-C15
Case Code (Metric) 3225
Case Code (Imperial) 1210
Number of Elements 2
Configuration Independent
Power Dissipation 65mW
Voltage - Forward (Vf) (Typ) 2.2V Green 2.1V Red
Viewing Angle 170°
Optoelectronic Device Type DUAL COLOR LED
Forward Current 20mA
Current - Test 20mA Green 20mA Red
Lens Style Rectangle with Flat Top
Lens Size 2.06mmx2.70mm
Luminous Intensity 2.5 mcd
Millicandela Rating 15mcd Green, 10mcd Red
Illumination Color Green, Red
Lens Transparency Diffused
Wavelength - Peak 570nm Green 630nm Red
Lens Color White
Reverse Voltage 5V
Wavelength - Dominant 572nm Green 626nm Red
Dimensions
Height 1.2mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
