5530111F
RoHS
RoHS compliant
RoHS compliantPackage /
Category Optoelectronics / LEDs - Circuit Board Indicators, Arrays, Light Bars, Bar Graphs
Description
LED 2HI 3MM RED PC MNT
PDF
/
Buying Options
Total Price: USD $2.04
Unit Price: USD $2.0416
≥1 USD $2.0416
≥10 USD $1.361536
≥100 USD $1.047728
≥500 USD $0.947109
≥1000 USD $0.813921
≥3000 USD $0.769525
Inventory: 1156
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Luminous Intensity-Min 0.001 cd
T-code T-1
Number of LEDs 2
Overall Height 9.65mm
Forward Voltage-Max 2V
Wavelength - Peak 650nm
Millicandela Rating 10mcd
Lens Type Diffused, Tinted
Luminous Intensity 10.0 mcd
Lens Size 3mm T-1
Lens Style Round with Domed Top
Optoelectronic Device Type SINGLE COLOR LED ARRAY
Viewing Angle 45°
Current 10mA
Configuration 2 High
Operating Temperature (Min) -25°C
Operating Temperature (Max) 85°C
Terminal Pitch 2.54mm
Number of Functions 2
Packing Method BAG
HTS Code 8541.40.20.00
Voltage - Rated 2V
Color Red (x 2)
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
Number of Terminations 4
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e1
Series 553
Published 2002
Packaging Bulk
Physical
Mounting Feature RADIAL MOUNT
Surface Mount NO
Mounting Type Through Hole, Right Angle
Supply Chain
Factory Lead Time 10 Weeks
