HSME-C120
RoHS
RoHS compliant
RoHS compliantPackage 2-SMD, No Lead
Category Optoelectronics / LED Indication - Discrete
Description
LED Uni-Color Green 570nm 2-Pin Chip LED T/R
PDF
/
Buying Options
Total Price: USD $0.47
Unit Price: USD $0.4664
≥1 USD $0.4664
≥10 USD $0.30448
≥100 USD $0.201256
≥500 USD $0.155364
≥1000 USD $0.140386
Inventory: 1250
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Height 600μm
Technical
Wavelength - Dominant 572nm
Reverse Voltage 5V
Lens Color Colorless
Wavelength - Peak 570nm
Lens Transparency Clear
Millicandela Rating 52mcd
Luminous Intensity 52 mcd
Lens Size 1.20mmx0.60mm
Lens Style Rectangle with Domed Top
Forward Current 20mA
Optoelectronic Device Type SINGLE COLOR LED
Viewing Angle 155°
Voltage - Forward (Vf) (Typ) 2.1V
Power Dissipation 52mW
Configuration Standard
Number of Elements 1
Base Part Number HSME-C120
Depth 600μm
Number of Functions 1
Packing Method TAPE AND REEL 7"
Power Rating 52mW
Subcategory Visible LEDs
Color Green
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Terminal Finish Gold (Au) - with Nickel (Ni) barrier
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 2A (4 Weeks)
Part Status Active
JESD-609 Code e4
Size / Dimension 1.60mm Lx1.00mm W
Published 2004
Packaging Tape & Reel (TR)
Physical
Shape RECTANGULAR
Number of Pins 2
Package / Case 2-SMD, No Lead
Mounting Type Surface Mount, Right Angle
Mount Surface Mount
Supply Chain
Factory Lead Time 13 Weeks
