HLMP-Q156
RoHS
RoHS compliant
RoHS compliantPackage Axial, Flat Leads
Category Optoelectronics / LED Indication - Discrete
Description
LED RED CLEAR AXIAL T/H
PDF
/
Inventory: 4443
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height (Max) 2.92mm
Technical
Wavelength - Dominant 644nm
Forward Current-Max 0.05A
Lens Transparency Clear
Lens Size 1.78mm Dia
Lens Style Round with Domed Top
Current - Test 20mA
Optoelectronic Device Type SINGLE COLOR LED
Viewing Angle 15°
Voltage - Forward (Vf) (Typ) 1.6V
Configuration Standard
Operating Temperature (Min) -55°C
Operating Temperature (Max) 100°C
Number of Functions 1
HTS Code 8541.40.20.00
Color Red
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
JESD-609 Code e3
Size / Dimension 2.21mm Lx2.09mm W
Physical
Package / Case Axial, Flat Leads
Mounting Type Through Hole
Supply Chain
Factory Lead Time 13 Weeks
