HLMP-EL30-PSKDD
RoHS
/
Package Radial
Category Optoelectronics / LED Indication - Discrete
Description
LED Uni-Color Amber 592nm 2-Pin T-1 3/4 Ammo
PDF
/
Inventory: 2123
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Length 5.8mm
Height 8.91mm
Technical
Wavelength - Dominant 590nm
Reverse Voltage 20V
Luminous Flux 500 mlm
Lens Color Colorless
Wavelength - Peak 592nm
Lens Transparency Clear
Illumination Color Orange
Millicandela Rating 1690mcd
Luminous Intensity 1.69 cd
Lens Size 5mm T-1 3/4
Lens Style Round with Domed Top
Current - Test 20mA
Forward Current 50mA
Optoelectronic Device Type SINGLE COLOR LED
Viewing Angle 30°
Voltage - Forward (Vf) (Typ) 2.02V
Configuration Standard
Number of Elements 1
Base Part Number HLMP-EL30
Depth 5.8mm
Number of Functions 1
Packing Method AMMO PACK
Additional Feature HIGH RELIABILITY
Color Amber
Min Operating Temperature -40°C
Max Operating Temperature 100°C
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e1
Published 2016
Packaging Tape & Box (TB)
Physical
Number of Pins 2
Package / Case Radial
Mounting Type Through Hole
Mount Through Hole
