SML-010DTT86
RoHS
RoHS compliant
RoHS compliantPackage 1208 (3020 Metric)
Category Optoelectronics / LED Indication - Discrete
Description
LED ORANGE CLEAR 3020 SMD
PDF
/
Buying Options
Total Price: USD $0.46
Unit Price: USD $0.4576
≥1 USD $0.4576
≥10 USD $0.3036
≥100 USD $0.20064
≥500 USD $0.154915
Inventory: 1142
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Height 1.5mm
Technical
Reverse Voltage-Max 4V
Number of LEDs 1
Lens Color Colorless
Wavelength - Peak 610nm
Lens Transparency Clear
Millicandela Rating 10mcd
Luminous Intensity 10 mcd
Lens Size 2.30mmx1.60mm
Lens Style Rectangle with Flat Top
Forward Current 20mA
Optoelectronic Device Type SINGLE COLOR LED
Viewing Angle 110 °
Voltage - Forward (Vf) (Typ) 2V
Configuration Standard
Case Code (Imperial) 1208
Case Code (Metric) 3020
Number of Functions 1
Packing Method TAPE AND REEL
Subcategory Visible LEDs
Color Orange
Min Operating Temperature -30°C
Max Operating Temperature 85°C
Terminal Finish Gold (Au) - with Nickel (Ni) barrier
Number of Terminations 2
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Not For New Designs
Pbfree Code yes
JESD-609 Code e4
Size / Dimension 3.00mm Lx2.00mm W
Series SML-01
Published 2001
Packaging Tape & Reel (TR)
Physical
Shape RECTANGULAR
Number of Pins 2
Package / Case 1208 (3020 Metric)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 10 Weeks
