HLMP-6700-G0011
RoHS
RoHS compliant
RoHS compliantPackage 2-SMD, Gull Wing
Category Optoelectronics / LED Indication - Discrete
Description
Standard LEDs - SMD Poly Dome Yellow
PDF
/
Inventory: 2342
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Height (Max) 2.92mm
Technical
Reverse Voltage-Max 5V
T-code T-3/4
Wavelength - Dominant 585nm
Overall Height 2.92mm
Forward Voltage-Max 2.4V
Forward Current-Max 0.02A
Wavelength - Peak 583nm
Lens Transparency Diffused
Millicandela Rating 5mcd
Luminous Intensity 5.0 mcd
Lens Size 1.78mm Dia
Lens Style Round with Domed Top
Current - Test 10mA
Optoelectronic Device Type SINGLE COLOR LED
Viewing Angle 90°
Voltage - Forward (Vf) (Typ) 2V
Configuration Standard
Operating Temperature (Min) -40°C
Operating Temperature (Max) 85°C
Base Part Number HLMP-6700
Reach Compliance Code compliant
Number of Functions 1
Packing Method TAPE AND REEL
Subcategory Visible LEDs
HTS Code 8541.40.20.00
Additional Feature TTL COMPATIBLE
Color Yellow
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 2A (4 Weeks)
Part Status Obsolete
JESD-609 Code e3
Size / Dimension 2.08mm Lx2.21mm W
Packaging Tape & Reel (TR)
Physical
Mounting Feature AXIAL MOUNT
Surface Mount NO
Package / Case 2-SMD, Gull Wing
Mounting Type Surface Mount
