HLMP-3762
RoHS
RoHS compliant
RoHS compliantPackage Radial
Category Optoelectronics / LED Indication - Discrete
Description
BROADCOM LIMITED HLMP-3762 LED, Red, Through Hole, T-1 3/4 (5mm), 10 mA, 1.9 V, 626 nm
PDF
/
Buying Options
Total Price: USD $0.7
Unit Price: USD $0.6952
≥1 USD $0.6952
≥10 USD $0.4532
≥100 USD $0.296912
≥500 USD $0.234406
≥1000 USD $0.218777
≥3000 USD $0.210962
Inventory: 1230
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 13 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case Radial
Number of Pins 2
Technical
Packaging Bulk
Published 2009
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Terminal Finish Tin (Sn)
Max Operating Temperature 100°C
Min Operating Temperature -40°C
Color Red
Subcategory Visible LEDs
Number of Functions 1
Depth 6.1mm
Base Part Number HLMP-3762
Lead Length 25mm
Number of Elements 1
Configuration Standard
Power Dissipation 85mW
Voltage - Forward (Vf) (Typ) 1.9V
Viewing Angle 60°
Optoelectronic Device Type SINGLE COLOR LED
Forward Current 10mA
Lens Style Round with Domed Top
Lens Size 5mm T-1 3/4
Luminous Intensity 8.6 mcd
Millicandela Rating 8.6mcd
Lens Transparency Diffused
Wavelength - Peak 635nm
Reverse Voltage 5V
Forward Voltage-Max 3V
Wavelength - Dominant 626nm
Dimensions
Diameter 5mm
Height 9.19mm
Length 6.1mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
