ASMT-UAB4-PU802
RoHS
RoHS compliant
RoHS compliantPackage 2-PLCC
Category Optoelectronics / LED Indication - Discrete
Description
LED Uni-Color Amber Chip LED 2-Pin PLCC
PDF
/
Buying Options
Total Price: USD $0.31
Unit Price: USD $0.308059
≥1 USD $0.308059
Inventory: 12009
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height (Max) 2.10mm
Width 2.8mm
Length 3.2mm
Height 2.1mm
Technical
Number of LEDs 1
Wavelength - Dominant 590nm
Lens Color Colorless
Wavelength - Peak 593nm
Lens Transparency Clear
Millicandela Rating 980mcd
Luminous Intensity 980 mcd
Forward Voltage 1.8V
Lens Style Round with Flat Top
Current - Test 20mA
Viewing Angle 120°
Voltage - Forward (Vf) (Typ) 1.8V
Configuration Standard
Color Amber
Min Operating Temperature -40°C
Max Operating Temperature 100°C
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Active
Size / Dimension 3.20mm Lx2.80mm W
Published 2012
Packaging Tape & Reel (TR)
Physical
Supplier Device Package 2-PLCC
Number of Pins 2
Package / Case 2-PLCC
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Silver
Supply Chain
Factory Lead Time 18 Weeks
