KO132B1501
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Keylock Switches
Description
SWITCH KEYLOCK 2POS SPDT 1A 125V
PDF
/
Buying Options
Total Price: USD $3.63
Unit Price: USD $3.634874
≥1 USD $3.634874
≥10 USD $3.429131
≥100 USD $3.235026
≥500 USD $3.051911
≥1000 USD $2.879159
Inventory: 7691
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Actuator Length 0.079 inch
Length - Termination 0.13 inch
Technical
Key Removable Positions All
Depth Behind Flange 18.30mm
Index Angle 90 °
Contact Timing Not Specified
Contact Current(AC)-Max 0.5A
Switch Type KEYLOCK SWITCH
Dielectric Withstanding Voltage 1000VAC V
Contact Resistance 0.01mOhm
Panel Cutout Dimensions Circular - 12.00mm Dia
Switch Function On-On
Circuit SPDT
Actuator Type Tubular Key
Voltage - Rated AC 125V
Termination Style Solder Lug
Contact Finish Silver
Current Rating (Amps) 1A AC
Number of Positions 2
ECCN Code EAR99
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series KO
Published 2008
Physical
Mounting Type Panel Mount
Mount Panel
Contact Material Copper Alloy
Supply Chain
Factory Lead Time 10 Weeks
