KO130NA126
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Keylock Switches
Description
SWITCH KEYLOCK 2POS SPDT 4A 125V
PDF
/
Inventory: 8150
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Contact Material Copper Alloy
Mount Panel
Mounting Type Panel Mount
Technical
Published 2008
Series KO
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Number of Positions 2
Current Rating (Amps) 4A AC
Current Rating 4A
Contact Finish Silver
Termination Style Solder Lug
Voltage - Rated AC 125V
Actuator Type Flat Key
Circuit SPDT
Switch Function On-On
Panel Cutout Dimensions Circular - 19.00mm Dia
Contact Timing Not Specified
Index Angle 90 °
Depth Behind Flange 28.20mm
Key Removable Positions 3 only
Compliance
RoHS Status ROHS3 Compliant
