CYP15G0401TB-BGXC
RoHS
RoHS compliant
RoHS compliantPackage 256-LBGA Exposed Pad
Category Integrated Circuits (ICs) / Interface - Telecom
Description
ROHS3Compliant BOTTOM BALL Obsolete Telecom IC Driver 0C~70C 27mm 590mA 3.135V~3.465V
PDF
/
Buying Options
Total Price: USD $50.85
Unit Price: USD $50.8464
≥1 USD $50.8464
Inventory: 574
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 27mm
Length 27mm
Technical
Telecom IC Type TELECOM CIRCUIT
Current - Supply 590mA
Nominal Supply Current 770mA
Number of Circuits 4
Interface LVTTL
Operating Supply Voltage 3.3V
Qualification Status Not Qualified
Function Driver
Base Part Number CY*15G04
Time@Peak Reflow Temperature-Max (s) 20
Reach Compliance Code unknown
Terminal Pitch 1.27mm
Supply Voltage 3.3V
Peak Reflow Temperature (Cel) 260
Terminal Form BALL
Terminal Position BOTTOM
Voltage - Supply 3.135V~3.465V
Technology BICMOS
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
Number of Terminations 256
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
JESD-609 Code e1
Series HOTlink II?
Published 2005
Packaging Tray
Operating Temperature 0°C~70°C
Physical
Number of Pins 256
Package / Case 256-LBGA Exposed Pad
Mounting Type Surface Mount
Mount Surface Mount
