LX5250CDB
RoHS
/
Package 36-QSOP
Category Integrated Circuits (ICs) / Interface - Signal Terminators
Description
Contains Lead Obsolete GULL WING RoHS Compliant signal terminator 0C~70C 105Ohm 2.64mm 5.25V
PDF
/
Inventory: 4552
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Width 7.5mm
Length 15.3mm
Height Seated (Max) 2.64mm
Technical
Pull-up Resistance-Nom 105Ohm
Number of Signal Lines 9
Differential Output YES
Operating Supply Voltage 5.25V
Pin Count 36
Base Part Number LX5250
Time@Peak Reflow Temperature-Max (s) 40
Terminal Pitch 0.8mm
Supply Voltage 4.75V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 4.75V~5.25V
Additional Feature SINGLE ENDED TERMINATION REQUIRES 3.5V TO 5.25V SUPPLY
Terminal Finish MATTE TIN
Type SCSI, LVD, SE
Number of Terminations 9
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e3
Published 2005
Packaging Tape & Reel (TR)
Operating Temperature 0°C~70°C
Physical
Number of Pins 36
Package / Case 36-QSOP
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status OBSOLETE (Last Updated: 1 month ago)
