LTC4304IDD#PBF
RoHS
RoHS compliant
RoHS compliantPackage 10-WFDFN Exposed Pad
Category Integrated Circuits (ICs) / Interface - Signal Buffers, Repeaters, Splitters
Description
Matte Tin (Sn) LTC4304 Tube CMOS signal repeater 3/5V 0.5mm -40C~85C 6mA
PDF
/
Buying Options
Total Price: USD $6.87
Unit Price: USD $6.8728
≥1 USD $6.8728
≥10 USD $6.21016
≥100 USD $5.921696
≥500 USD $5.141673
≥1000 USD $4.91062
≥3000 USD $4.477326
Inventory: 322
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 3mm
Length 3mm
Height Seated (Max) 0.8mm
Technical
Capacitance - Input 10pF
Data Rate (Max) 400kHz
Input 2-Wire Bus
Current - Supply 6mA
Number of Channels 2
Power Supplies 3/5V
Pin Count 10
Output 2-Wire Bus
Base Part Number LTC4304
Time@Peak Reflow Temperature-Max (s) 30
Terminal Pitch 0.5mm
Supply Voltage 3.3V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Position DUAL
Voltage - Supply 2.7V~5.5V
Technology CMOS
Subcategory Other Interface ICs
Applications I2C - Hotswap
Terminal Finish Matte Tin (Sn)
Type Buffer, Accelerator
ECCN Code EAR99
Number of Terminations 10
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Published 2006
Packaging Tube
Operating Temperature -40°C~85°C
Physical
Number of Pins 10
Package / Case 10-WFDFN Exposed Pad
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status PRODUCTION (Last Updated: 3 weeks ago)
Factory Lead Time 8 Weeks
