MAX9254EUM/V+
RoHS
RoHS compliant
RoHS compliantPackage 48-TFSOP (0.240, 6.10mm Width)
Category Integrated Circuits (ICs) / Interface - Serializers, Deserializers
Description
LINE RECEIVER MAX9254 Tube LVDS interface serializer 12.5mm 3V~3.6V 840Mbps -40C~85C TA
PDF
/
Inventory: 6107
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Surface Mount
Package / Case 48-TFSOP (0.240, 6.10mm Width)
Surface Mount YES
Number of Pins 48
Weight 420.990418mg
Technical
Operating Temperature -40°C~85°C TA
Packaging Tube
Published 2010
Series Automotive, AEC-Q100
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 48
ECCN Code EAR99
Voltage - Supply 3V~3.6V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) NOT SPECIFIED
Supply Voltage 3.3V
Terminal Pitch 0.5mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number MAX9254
Function Deserializer
Number of Outputs 21
Qualification Status Not Qualified
Output Type LVCMOS, LVTTL
Operating Supply Voltage 3.6V
Input Type LVDS
Data Rate 840Mbps
Number of Inputs 3
Differential Output YES
Input Characteristics STANDARD
Interface IC Type LINE RECEIVER
Receiver Number of Bits 3
Interface Standard EIA-644; TIA-644
Dimensions
Height Seated (Max) 1.1mm
Length 12.5mm
Width 6.1mm
Compliance
RoHS Status ROHS3 Compliant
