MCP23008-E/SS
RoHS
RoHS compliant
RoHS compliantPackage 20-SSOP (0.209, 5.30mm Width)
Category Integrated Circuits (ICs) / Interface - I/O Expanders
Description
MCP23008 Tube Active I2C io expander 5V 7.2mm 1.7MHz 1mA
PDF
/
Buying Options
Total Price: USD $1.31
Unit Price: USD $1.3112
≥1 USD $1.3112
≥10 USD $1.1
≥100 USD $0.9944
Inventory: 5772
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 2 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 20-SSOP (0.209, 5.30mm Width)
Number of Pins 20
Technical
Operating Temperature -40°C~125°C
Packaging Tube
Published 2005
JESD-609 Code e3
Feature POR
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 20
ECCN Code EAR99
Terminal Finish Matte Tin (Sn) - annealed
Technology CMOS
Voltage - Supply 1.8V~5.5V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Supply Voltage 5V
Terminal Pitch 0.65mm
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number MCP23008
Pin Count 20
Qualification Status Not Qualified
Output Type Push-Pull
Power Supplies 5V
Number of Channels 1
Interface I2C
Number of I/O 8
Number of Ports 1
Nominal Supply Current 1mA
Power Dissipation 700mW
Output Current 25mA
Number of Bits 8
Clock Frequency 1.7MHz
Interrupt Output Yes
Dimensions
Height Seated (Max) 2mm
Length 7.2mm
Width 5.3mm
Compliance
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
