MAX7407ESA+T
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Interface - Filters - Active
Description
Tape & Reel (TR) MAX7407 Elliptic Low Pass Switched Capacitor e3 interface filter 3V 4.9mm 10kHz 85C
PDF
/
Buying Options
Total Price: USD $10
Unit Price: USD $9.996421
≥1 USD $9.996421
≥200 USD $3.98859
≥500 USD $3.855987
≥1000 USD $3.790342
Inventory: 1101
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 3.9mm
Length 4.9mm
Technical
Response LOWPASS
Frequency - Cutoff or Center 10kHz
Filter Order 8th
Filter Type Elliptic, Low Pass Switched Capacitor
Supply Current-Max (Isup) 3.5mA
Nominal Supply Current 2mA
Number of Circuits 1
Supply Voltage-Min (Vsup) 2.7V
Temperature Grade INDUSTRIAL
Power Supplies 3V
Supply Voltage-Max (Vsup) 3.6V
Operating Supply Voltage 3V
Pin Count 8
Base Part Number MAX7407
Supply Voltage 3V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 2.7V~3.6V
Technology CMOS
Min Operating Temperature -40°C
Max Operating Temperature 85°C
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Published 1999
Packaging Tape & Reel (TR)
Physical
Number of Pins 8
Surface Mount YES
Package / Case 8-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Contact Plating Tin
Supply Chain
Factory Lead Time 6 Weeks
