MAX281ACPA+
RoHS
RoHS compliant
RoHS compliantPackage 8-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / Interface - Filters - Active
Description
ROHS3Compliant Lead Free Active COMMERCIAL Filter IC 5mA 70C 20kHz 9.375mm
PDF
/
Buying Options
Total Price: USD $13.6
Unit Price: USD $13.6048
≥1 USD $13.6048
≥10 USD $12.5048
≥100 USD $11.986832
≥500 USD $10.56132
≥1000 USD $10.042982
≥3000 USD $9.395056
Inventory: 113
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 7.62mm
Length 9.375mm
Height Seated (Max) 4.572mm
Technical
Poles and Zeros 5 AND 0
Response LOWPASS
Neg Supply Voltage-Min (Vsup) -2.375V
Frequency - Cutoff or Center 20kHz
Filter Order 5th
Neg Supply Voltage-Nom (Vsup) -5V
Filter Type Bessel, Low Pass Switched Capacitor
Nominal Supply Current 5mA
Number of Circuits 1
Supply Voltage-Min (Vsup) 2.375V
Temperature Grade COMMERCIAL
Power Supplies +-5V
Supply Voltage-Max (Vsup) 8V
Pin Count 8
Base Part Number MAX281
Time@Peak Reflow Temperature-Max (s) 30
Terminal Pitch 2.54mm
Supply Voltage 5V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Position DUAL
Voltage - Supply 4.75V~16V ±2.375V~8V
Additional Feature ZERO DC ERROR
Min Operating Temperature 0°C
Max Operating Temperature 70°C
Terminal Finish Tin (Sn)
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Published 1996
Packaging Tube
Physical
Number of Pins 8
Surface Mount NO
Package / Case 8-DIP (0.300, 7.62mm)
Mounting Type Through Hole
Supply Chain
Factory Lead Time 6 Weeks
