MAX268AENG
RoHS
/
Package 24-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / Interface - Filters - Active
Description
Tube MAX268 Band Pass e0 interface filter -6.3V 30.545mm 140kHz 85C
PDF
/
Buying Options
Total Price: USD $191.17
Unit Price: USD $191.17135
≥1 USD $191.17135
≥10 USD $171.39425
Inventory: 504
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Radiation Hardening No
Dimensions
Length 30.545mm
Technical
Transfer Characteristics PIN PROGRAMMABLE
Response BANDPASS
Frequency - Cutoff or Center 140kHz
Filter Order 2nd
Neg Supply Voltage-Max (Vsup) -6.3V
Neg Supply Voltage-Nom (Vsup) -5V
Filter Type Band Pass
Nominal Supply Current 14mA
Number of Circuits 2
Temperature Grade INDUSTRIAL
Supply Voltage-Max (Vsup) 6.3V
Pin Count 24
Base Part Number MAX268
Time@Peak Reflow Temperature-Max (s) 20
Supply Voltage 5V
Number of Functions 2
Peak Reflow Temperature (Cel) 240
Terminal Position DUAL
Voltage - Supply 4.74V~12.6V ±2.37V~6.3V
Technology CMOS
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Terminal Finish Tin/Lead (Sn85Pb15)
Type Active
ECCN Code EAR99
Number of Terminations 24
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code no
JESD-609 Code e0
Published 2008
Packaging Tube
Physical
Weight 3.740011g
Number of Pins 24
Package / Case 24-DIP (0.300, 7.62mm)
Mounting Type Through Hole
Mount Through Hole
