MAX260ACNG+
RoHS
RoHS compliant
RoHS compliantPackage 24-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / Interface - Filters - Active
Description
ROHS3Compliant Lead Free Not Qualified Obsolete Filter IC 70C 7.5kHz 30.545mm -6.3V
PDF
/
Inventory: 2530
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Length 30.545mm
Technical
Transfer Characteristics DIGITALLY PROGRAMMABLE
Number of Filters 2
Frequency - Cutoff or Center 7.5kHz
Filter Order 2nd
Neg Supply Voltage-Max (Vsup) -6.3V
Neg Supply Voltage-Nom (Vsup) -5V
Filter Type Universal Switched Capacitor
Temperature Grade COMMERCIAL
Supply Voltage-Max (Vsup) 6.3V
Operating Temperature (Max) 70°C
Qualification Status Not Qualified
Pin Count 24
Base Part Number MAX260
Time@Peak Reflow Temperature-Max (s) 30
Supply Voltage 5V
Number of Functions 2
Peak Reflow Temperature (Cel) 260
Terminal Position DUAL
Voltage - Supply ±5V
Technology CMOS
Subcategory Active Filters
Additional Feature IT CAN ALSO BE OPERATED FROM A SINGLE 5V SUPPLY
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e3
Published 2003
Packaging Tube
Physical
Surface Mount NO
Package / Case 24-DIP (0.300, 7.62mm)
Mounting Type Through Hole
