SN65LVDS9638DGNRG4
RoHS
RoHS compliant
RoHS compliantPackage 8-TSSOP, 8-MSOP (0.118, 3.00mm Width) Exposed Pad
Category Integrated Circuits (ICs) / Interface - Drivers, Receivers, Transceivers
Description
EAR99 65LVDS9638 Tape & Reel (TR) LVDS interface receiver 3.3V 35mA 18.99418mg 4.5ns
PDF
/
Buying Options
Total Price: USD $2.15
Unit Price: USD $2.1489
≥1 USD $2.1489
≥10 USD $1.7632
≥100 USD $1.7081
≥500 USD $1.653
≥1000 USD $1.5979
Inventory: 80
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 1 week ago)
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 8-TSSOP, 8-MSOP (0.118, 3.00mm Width) Exposed Pad
Number of Pins 8
Weight 18.99418mg
Technical
Operating Temperature -40°C~85°C
Packaging Tape & Reel (TR)
Series 65LVDS
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
ECCN Code EAR99
Type Driver
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Technology CMOS
Voltage - Supply 3V~3.6V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 2
Supply Voltage 3.3V
Terminal Pitch 0.65mm
Base Part Number 65LVDS9638
Pin Count 8
Operating Supply Voltage 3.3V
Propagation Delay 4.5 ns
Supply Current-Max 35mA
Turn On Delay Time 4.5 ns
Data Rate 400Mbps
Output Characteristics 3-STATE
Differential Output YES
Output Polarity COMPLEMENTARY
Protocol LVDS
Input Characteristics STANDARD
Number of Drivers/Receivers 2/0
Interface Standard EIA-644; TIA-644
Number of Drivers 2
Supply Voltage1-Nom 3.3V
Dimensions
Height 1.1mm
Length 3mm
Width 3mm
Thickness 1.02mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
