SN65LVDM1676DGG

Texas Instruments
RoHS
RoHS RoHS compliant
Package 64-TFSOP (0.240, 6.10mm Width)
Category Integrated Circuits (ICs) / Interface - Drivers, Receivers, Transceivers
Description EAR99 65LVDM1676 Tube LVDS interface receiver 3.3V 175mA 262.601633mg 4.5ns
PDF
/
Buying Options
Total Price: USD $12.81
Unit Price: USD $12.8128
≥1 USD $12.8128
≥10 USD $11.7744
≥100 USD $11.286176
≥500 USD $9.944176
≥1000 USD $9.456128
≥3000 USD $8.846042
Inventory: 114
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 5 days ago)

Physical

Mount Surface Mount
Mounting Type Surface Mount
Package / Case 64-TFSOP (0.240, 6.10mm Width)
Number of Pins 64
Weight 262.601633mg

Technical

Operating Temperature -40°C~85°C
Packaging Tube
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 2 (1 Year)
Number of Terminations 64
ECCN Code EAR99
Type Transceiver
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
HTS Code 8542.39.00.01
Subcategory Line Driver or Receivers
Technology CMOS
Voltage - Supply 3V~3.6V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 16
Supply Voltage 3.3V
Terminal Pitch 0.5mm
Base Part Number 65LVDM1676
Pin Count 64
Operating Supply Voltage 3.3V
Number of Elements 16
Nominal Supply Current 175mA
Power Dissipation 2.094W
Propagation Delay 4.5 ns
Turn On Delay Time 4.5 ns
Data Rate 200Mbps
Differential Output YES
Protocol LVDS
Input Characteristics DIFFERENTIAL
Number of Drivers/Receivers 16/16
Driver Number of Bits 16
Receiver Number of Bits 16
Duplex Half
Interface Standard GENERAL PURPOSE
Input Current 175mA
Transmit Delay-Max 3.6 ns
Supply Voltage1-Nom 3.3V
Output Low Current-Max 0.008A
Out Swing-Min 0.247 V

Dimensions

Height 1.2mm
Length 17mm
Width 6.1mm
Thickness 1.15mm

Compliance

Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
