MAX3238IDB
RoHS
RoHS compliant
RoHS compliantPackage 28-SSOP (0.209, 5.30mm Width)
Category Integrated Circuits (ICs) / Interface - Drivers, Receivers, Transceivers
Description
EAR99 MAX3238 Tube RS232 interface transceiver 5V 2mA 208.397344mg 250kbps
PDF
/
Buying Options
Total Price: USD $5.37
Unit Price: USD $5.37035
≥1 USD $5.37035
≥10 USD $4.4061
≥100 USD $4.26835
≥500 USD $4.1306
≥1000 USD $3.99285
Inventory: 1568
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Thickness 1.95mm
Width 5.3mm
Length 10.2mm
Height 2mm
Technical
Number of Receivers 3
Supply Voltage1-Nom 5V
Simplex/Duplex Full Duplex
Number of Transceivers 1
Number of Drivers 5
Receiver Hysteresis 300mV
Duplex Full
Number of Drivers/Receivers 5/3
Input Characteristics SCHMITT TRIGGER
Protocol RS232
Differential Output NO
Data Rate 250kbps
Logic Function Receiver, Transceiver
Nominal Supply Current 2mA
Operating Supply Voltage 5V
Pin Count 28
Base Part Number MAX3238
Supply Voltage 3.3V
Number of Functions 3
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 3V~5.5V
Technology BIPOLAR
Subcategory Line Driver or Receivers
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Type Transceiver
ECCN Code EAR99
Number of Terminations 28
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Packaging Tube
Operating Temperature -40°C~85°C
Physical
Weight 208.397344mg
Number of Pins 28
Package / Case 28-SSOP (0.209, 5.30mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 1 week ago)
Factory Lead Time 6 Weeks
