DS34LV87TMX/NOPB
RoHS
RoHS compliant
RoHS compliantPackage 16-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Interface - Drivers, Receivers, Transceivers
Description
EAR99 DS34LV87 Tape & Reel (TR) RS422RS485 interface transceiver 3.3V 100muA 155.100241mg 30Mbps
PDF
/
Buying Options
Total Price: USD $2.26
Unit Price: USD $2.2616
≥1 USD $2.2616
≥10 USD $2.03192
≥100 USD $1.91664
≥500 USD $1.632928
≥1000 USD $1.533242
≥3000 USD $1.341578
Inventory: 1176
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Thickness 1.58mm
Width 3.91mm
Length 9.9mm
Height 1.75mm
Technical
High Level Input Current-Max 0.00001A
Out Swing-Min 2 V
Supply Voltage1-Nom 3.3V
ESD Protection Yes
Number of Drivers 4
Number of Drivers/Receivers 4/0
Input Characteristics STANDARD
Protocol RS422, RS485
Output Polarity TRUE
Differential Output YES
Output Characteristics 3-STATE
Data Rate 30 Mbps
Max Supply Current 100μA
Nominal Supply Current 100μA
Operating Supply Current 100μA
Operating Supply Voltage 3.3V
Pin Count 16
Base Part Number DS34LV87
Terminal Pitch 1.27mm
Supply Voltage 3.3V
Number of Functions 4
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 3V~3.6V
Technology CMOS
Type Driver
ECCN Code EAR99
Number of Terminations 16
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C
Physical
Weight 155.100241mg
Number of Pins 16
Package / Case 16-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Tin
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 2 days ago)
Factory Lead Time 6 Weeks
