MAX489MJD
RoHS
RoHS compliant
RoHS compliantPackage 14-CDIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / Interface - Drivers, Receivers, Transceivers
Description
e0 14-CDIP (0.300 7.62mm) RS422RS485 EIA-422; EIA-485 interface transceiver 5V 250muA 5.08mm 2000ns
PDF
/
Buying Options
Total Price: USD $138.25
Unit Price: USD $138.24685
≥1 USD $138.24685
≥10 USD $133.6384
≥100 USD $119.814
Inventory: 703
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Physical
Mounting Type Through Hole
Package / Case 14-CDIP (0.300, 7.62mm)
Surface Mount NO
Number of Pins 14
Technical
Operating Temperature -55°C~125°C
Published 2012
JESD-609 Code e0
Pbfree Code no
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Type Transceiver
Terminal Finish TIN LEAD
Subcategory Line Driver or Receivers
Technology CMOS
Voltage - Supply 4.75V~5.25V
Terminal Position DUAL
Peak Reflow Temperature (Cel) 245
Number of Functions 1
Supply Voltage 5V
Terminal Pitch 2.54mm
Reach Compliance Code not_compliant
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Pin Count 14
Qualification Status Not Qualified
Operating Supply Voltage 5V
Power Supplies 5V
Nominal Supply Current 250μA
Logic Function Receiver, Transceiver
Data Rate 250kbps
Output Characteristics 3-STATE
Differential Output YES
Output Polarity COMPLEMENTARY
Protocol RS422, RS485
Input Characteristics DIFFERENTIAL SCHMITT TRIGGER
Number of Drivers/Receivers 1/1
Driver Number of Bits 1
Receiver Number of Bits 1
Duplex Full
Receiver Hysteresis 70mV
Interface Standard EIA-422; EIA-485
Receive Delay-Max 2000 ns
Transmit Delay-Max 2000 ns
Output Low Current-Max 0.004A
Number of Transmitters 1
Dimensions
Height Seated (Max) 5.08mm
Width 7.62mm
Compliance
RoHS Status ROHS3 Compliant
