MAX234EPE
RoHS
/
Package 16-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / Interface - Drivers, Receivers, Transceivers
Description
Non-RoHS Compliant SCHMITT TRIGGER 2013 Driver Driver -40C~85C 5V 120Kbps 10000ns
PDF
/
Inventory: 3790
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Through Hole
Package / Case 16-DIP (0.300, 7.62mm)
Surface Mount NO
Technical
Operating Temperature -40°C~85°C
Packaging Tube
Published 2013
JESD-609 Code e0
Pbfree Code no
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 16
ECCN Code EAR99
Type Driver
Terminal Finish Tin/Lead (Sn/Pb)
Additional Feature EXTERNAL CHARGE PUMP
HTS Code 8542.39.00.01
Technology CMOS
Voltage - Supply 4.5V~5.5V
Terminal Position DUAL
Peak Reflow Temperature (Cel) 240
Number of Functions 4
Supply Voltage 5V
Terminal Pitch 2.54mm
Reach Compliance Code not_compliant
Time@Peak Reflow Temperature-Max (s) 20
Base Part Number MAX234
Pin Count 16
JESD-30 Code R-PDIP-T16
Qualification Status Not Qualified
Power Supplies 5V
Data Rate 120Kbps
Differential Output NO
Protocol RS232
Input Characteristics SCHMITT TRIGGER
Number of Drivers/Receivers 4/0
Driver Number of Bits 4
Interface Standard EIA-232-E; TIA-232-E; V.28; V.24
Receive Delay-Max 10000 ns
Transmit Delay-Max 10000 ns
Out Swing-Min 10 V
Dimensions
Height Seated (Max) 4.572mm
Length 19.175mm
Width 7.62mm
Compliance
RoHS Status Non-RoHS Compliant
