USB2514I-HZH
RoHS
RoHS compliant
RoHS compliantPackage 48-VFQFN Exposed Pad
Category Integrated Circuits (ICs) / Interface - Controllers
Description
USB2514 Tray e3 2007 interface controller 3V~3.6V 950mum 175mA 480Mbps
PDF
/
Buying Options
Total Price: USD $4.03
Unit Price: USD $4.028
≥1 USD $4.028
≥10 USD $3.30505
≥100 USD $3.2015
≥500 USD $3.09795
≥1000 USD $2.99535
Inventory: 641
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Width 6.15mm
Length 6.15mm
Height 950μm
Technical
Bus Compatibility I2C; SMBUS
Standards USB 2.0
ESD Protection Yes
Number of Transceivers 1
Protocol USB
Data Rate 480 Mbps
uPs/uCs/Peripheral ICs Type BUS CONTROLLER, UNIVERSAL SERIAL BUS
Number of Ports 4
Operating Supply Current 175mA
Operating Supply Voltage 3.3V
Function Hub Controller
Base Part Number USB2514
Terminal Pitch 0.5mm
Supply Voltage 3.3V
Terminal Position QUAD
Voltage - Supply 3V~3.6V
Technology CMOS
Terminal Finish Matte Tin (Sn) - annealed
Number of Terminations 48
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
JESD-609 Code e3
Published 2007
Packaging Tray
Operating Temperature 0°C~70°C
Physical
Number of Pins 36
Package / Case 48-VFQFN Exposed Pad
Mount Surface Mount
Supply Chain
Factory Lead Time 3 Weeks
