70G-ODC15
RoHS
/
Package Module
Category Relays / I/O Relay Modules
Description
OUTPUT MODULE DC G5 9MA 15VDC
PDF
/
Buying Options
Total Price: USD $18.04
Unit Price: USD $18.04
≥1 USD $18.04
≥10 USD $17.14064
≥100 USD $16.238464
≥500 USD $15.336288
≥1000 USD $14.434112
≥3000 USD $13.531971
Inventory: 97
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Mount PCB, Screw, Through Hole
Package / Case Module
Number of Pins 4
Technical
Published 2007
Series 70
Feature Hold Down Screw, Fused, Status LED(s)
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination PC Pins
Type DC Output Module
Resistance 1.5kOhm
Max Operating Temperature 100°C
Min Operating Temperature -40°C
Color Red
Depth 11.684mm
Style G5
Approval Agency CE, CSA, TUV, UL
Housing Color Red
Output Type Digital
Number of Channels 1
Voltage - Input 15VDC
Current - Output 3.5A
Number of Poles 1
Throw Configuration SPST
Turn On Delay Time 20 μs
Voltage - Output 3V~60VDC
Min Input Voltage 10V
Max Input Voltage 20V
Turn-Off Delay Time 50 μs
Turn On Time 0.02ms
Max Input Voltage (DC) 60V
Turn Off Time 0.05ms
Current - Input 9mA
Dimensions
Height 55.9mm
Length 48.26mm
Width 55.88mm
Compliance
RoHS Status Non-RoHS Compliant
Lead Free Lead Free
