3404.0014.24
RoHS
RoHS compliant
RoHS compliantPackage 2-SMD, J-Lead
Category Circuit Protection / Fuses
Description
FUSE BRD MNT 3A 125VAC/VDC 2SMD
PDF
/
Inventory: 969
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Height 2.5908mm
Technical
Pre-arcing Time-Min 10ms
Joule Integral-Nom 1 J
Blow Characteristic VERY FAST
Circuit Protection Type ELECTRIC FUSE
Melting I2t 1.3
Breaking Capacity @ Rated Voltage 100A
Fuse Type Board Mount (Cartridge Style Excluded)
Response Time Fast Blow
Max Voltage Rating (DC) 125V
Max Voltage Rating (AC) 125V
Body Breadth 3.1 mm
Body Length or Diameter 7.4mm
Approval Agency cURus
Voltage - Rated AC 125V
Reference Standard CCC; CSA; CUL; UL
Current Rating 3A
Packing Method BLISTER TAPE AND REEL
Voltage - Rated DC 125V
HTS Code 8536.10.00.40
ECCN Code EAR99
Moisture Sensitivity Level (MSL) Vendor Undefined
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Size / Dimension 0.291Lx0.122W x 0.102 H 7.40mmx3.10mmx2.60mm
Series OMF 125
Packaging Tape & Reel (TR)
Operating Temperature -55°C~125°C
Physical
Weight 80.002354mg
Number of Pins 2
Terminal Shape WRAPAROUND
Package / Case 2-SMD, J-Lead
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Tin
Supply Chain
Factory Lead Time 29 Weeks
