CDSOD323-T05C
RoHS
RoHS compliant
RoHS compliantPackage SC-76, SOD-323
Category Circuit Protection / TVS - Diodes
Description
BOURNS - CDSOD323-T05C - TVS Diode, CDSOD323 Series, Bidirectional, 5 V, 18.3 V, SOD-323, 2 Pins
PDF
/
Buying Options
Total Price: USD $0.56
Unit Price: USD $0.5632
≥1 USD $0.5632
≥10 USD $0.49104
≥100 USD $0.339944
≥500 USD $0.284064
≥1000 USD $0.241754
Inventory: 37672
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case SC-76, SOD-323
Number of Pins 2
Diode Element Material SILICON
Contact Plating Tin
Technical
Operating Temperature -55°C~150°C TJ
Packaging Cut Tape (CT)
Max Junction Temperature (Tj) 150°C
ESD Protection Yes
Max Breakdown Voltage 6V
Reverse Breakdown Voltage 6V
Capacitance @ Frequency 3pF @ 1MHz
Rep Pk Reverse Voltage-Max 5V
Breakdown Voltage 6V
Test Current 1mA
Direction Bidirectional
Peak Pulse Power 350W
Max Surge Current 17A
Reverse Standoff Voltage 5V
Peak Pulse Current 17A
Clamping Voltage 18.3V
Voltage - Clamping (Max) @ Ipp 18.3V Typ
Max Reverse Leakage Current 5μA
Current - Peak Pulse (10/1000μs) 17A 8/20μs
Power Line Protection No
Element Configuration Single
Leakage Current 5μA
Number of Channels 1
Working Voltage 5V
Number of Elements 2
Pin Count 2
Base Part Number CDSOD323
Depth 1.45mm
Terminal Form GULL WING
Terminal Position DUAL
Technology AVALANCHE
Max Power Dissipation 350W
Subcategory Transient Suppressors
Capacitance 3pF
Additional Feature LOW CAPACITANCE
Applications General Purpose
Type Zener
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Published 2008
Supply Chain
Factory Lead Time 7 Weeks
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Dimensions
Width 1.45mm
Length 1.9mm
Height 1.14mm
