ICP-S0.5TN
RoHS
RoHS compliant
RoHS compliantPackage 2-SMD, J-Lead
Category Circuit Protection / Fuses
Description
FUSE BRD MNT 500MA 50VAC/VDC SMD
PDF
/
Inventory: 8385
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 2-SMD, J-Lead
Technical
Operating Temperature -55°C~125°C
Packaging Tape & Reel (TR)
Series ICP-S
Size / Dimension 0.118Lx0.098W x 0.079 H 3.00mmx2.50mmx2.00mm
JESD-609 Code e2
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Resistance 150mOhm
Terminal Finish TIN COPPER
Additional Feature UL RECOGNIZED
HTS Code 8541.30.00.80
Voltage - Rated DC 50V
Terminal Position DUAL
Terminal Form C BEND
Peak Reflow Temperature (Cel) 260
Current Rating 500mA
Time@Peak Reflow Temperature-Max (s) 10
JESD-30 Code R-PDSO-C2
Voltage - Rated AC 50V
Qualification Status Not Qualified
Number of Elements 1
Configuration SINGLE
Response Time Fast Blow
Fuse Type Board Mount (Cartridge Style Excluded)
DC Cold Resistance 0.15Ohm
Trigger Device Type SILICON SURGE PROTECTOR
Dimensions
Height 2.0066mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
