4430.2307
RoHS
RoHS compliant
RoHS compliantPackage /
Category Circuit Protection / Circuit Breakers
Description
Circuit Breakers TA45 BLK ROCKER 0.5A
PDF
/
Buying Options
Total Price: USD $18.08
Unit Price: USD $18.084
≥1 USD $18.084
≥10 USD $13.38216
≥100 USD $13.304544
Inventory: 62
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Width 25mm
Length 48mm
Height 34mm
Technical
Breaker Type Thermal
Number of Poles 2
Actuator Type Rocker
Approval Agency CSA C22.2 No 235, EN 60934, GB 17701, IEC 60934, UL1077
Voltage - Rated AC 240V
Current Rating 500mA
Current Rating (Amps) 500mA
Voltage - Rated DC 60V
Voltage - Rated 240V
Color White
Min Operating Temperature -10°C
Max Operating Temperature 55°C
Termination Quick Connect
Moisture Sensitivity Level (MSL) Vendor Undefined
Part Status Active
Series TA45
Physical
Weight 32.700013g
Mounting Type Panel Mount
Mount Snap in
Supply Chain
Factory Lead Time 22 Weeks
