166.7000.4506
RoHS
RoHS compliant
RoHS compliantPackage Blade, ATO/ATC
Category Circuit Protection / Fuses
Description
LITTELFUSE 166.7000.4506 Automotive Fuse, FKS ATO Series, 5 A, Time Delay, 80 V, 19mm x 5mm x 19.7mm
PDF
/
Inventory: 9157
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Holder, Socket
Mounting Type Holder
Package / Case Blade, ATO/ATC
Terminal Shape TAB/BLADE
Number of Pins 2
Housing Material Thermoplastic
Technical
Packaging Bulk
Series FKS ATO?
Size / Dimension 0.748Lx0.197W x 0.520 H 19.00mmx5.00mmx13.20mm
JESD-609 Code e3
Part Status Discontinued
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Resistance 20.6mOhm
Terminal Finish Matte Tin (Sn)
Color Tan
Voltage - Rated DC 80V
Depth 5mm
Current Rating 5A
Reference Standard CSA; UL
Voltage - Rated AC 80V
Approval Agency cULus
Body Length or Diameter 19mm
Current 5A
Response Time Slow Blow
Fuse Type Automotive
Breaking Capacity @ Rated Voltage 1kA
Melting I2t 24.3
DC Cold Resistance 0.0206Ohm
Circuit Protection Type Electric Fuse
Blow Characteristic TIME LAG
Fuse Size ATO
Fuse Current 5A
Fuse Class Supplemental
Dimensions
Height 13.208mm
Compliance
Radiation Hardening No
REACH SVHC Unknown
RoHS Status ROHS3 Compliant
Flammability Rating UL94 V-0
Lead Free Lead Free
