0473003.MRT1
RoHS
/
Package Axial
Category Circuit Protection / Fuses
Description
FUSE BRD MNT 3A 125VAC/VDC AXIAL
PDF
/
Inventory: 954
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Through Hole
Package / Case Axial
Surface Mount NO
Terminal Shape PIN WIRE
Technical
Operating Temperature -55°C~125°C
Packaging Tape & Reel (TR)
Series PICO? II 473
Size / Dimension 0.135Diax0.280L 3.43mmx7.11mm
JESD-609 Code e3
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Terminal Finish Tin (Sn)
HTS Code 8536.10.00.40
Current Rating (Amps) 3A
Packing Method TAPE AND REEL
Reach Compliance Code not_compliant
Reference Standard CSA; PSE; UL
Voltage - Rated AC 125V
Approval Agency CSA, PSE, UR
Body Length or Diameter 3.43mm
Physical Dimension 3.43mm x 7.11mm
Response Time Slow Blow
Fuse Type Board Mount (Cartridge Style Excluded)
Breaking Capacity @ Rated Voltage 50A
Rated Current 3A
Melting I2t 21
DC Cold Resistance 0.038Ohm
Circuit Protection Type ELECTRIC FUSE
Blow Characteristic TIME LAG
Joule Integral-Nom 21 J
Rated Voltage(DC) 125V
Dimensions
Body Height 7.11mm
Compliance
RoHS Status Non-RoHS Compliant
