0251004.HAT1L
RoHS
RoHS compliant
RoHS compliantPackage Axial
Category Circuit Protection / Fuses
Description
Fuse Subminiature Very Fast Acting 4A 125V Axial 2.8 X 7.11mm Ceramic Ammo Pack
PDF
/
Buying Options
Total Price: USD $1.05
Unit Price: USD $1.0472
≥1 USD $1.0472
≥10 USD $1.01728
≥100 USD $0.95216
≥500 USD $0.787776
Inventory: 213
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Body Height 7.11mm
Technical
Fuse Class Supplemental
Joule Integral-Nom 2 J
Blow Characteristic VERY FAST
Circuit Protection Type ELECTRIC FUSE
DC Cold Resistance 0.0204Ohm
Melting I2t 2.45
Wire/Cable Diameter 640 μm
Breaking Capacity @ Rated Voltage 50A AC 300A DC
Fuse Type Board Mount (Cartridge Style Excluded)
Response Time Fast Blow
Current 4A
Approval Agency CCC, CSA, cURus, PSE, TUV
Voltage - Rated AC 125V
Reference Standard CCC; CSA; PSE; QPL; TUV; UL
Current Rating 4A
Packing Method AMMO PACK
Voltage - Rated DC 125V
HTS Code 8536.10.00.40
Terminal Finish Matte Tin (Sn)
Resistance 20.4mOhm
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code no
JESD-609 Code e3
Size / Dimension 0.110Diax0.280L 2.80mmx7.11mm
Series PICO? II 251
Packaging Tape & Box (TB)
Operating Temperature -55°C~125°C
Physical
Body Material Ceramic
Number of Pins 2
Terminal Shape PIN WIRE
Package / Case Axial
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 12 Weeks
