142.6185.4106

Littelfuse Inc.
RoHS
RoHS RoHS compliant
Package Blade, ATO/ATC
Category Circuit Protection / Fuses
Description Fuse ATO 1 A 58 VDC black, 142.6185.4106, Littelfuse
PDF
/
Inventory: 6356
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Lead Free Lead Free
RoHS Status ROHS3 Compliant

Dimensions

Height 13.208mm

Technical

Joule Integral-Nom 2 J
Circuit Protection Type ELECTRIC FUSE
DC Cold Resistance 0.108Ohm
Melting I2t 2
Breaking Capacity @ Rated Voltage 1kA
Fuse Type Automotive
Response Time Fast Blow
Body Length or Diameter 19mm
Approval Agency cULus
Reference Standard UL
Current Rating 1A
Reach Compliance Code unknown
Depth 5mm
Voltage - Rated DC 58V
Color Black
Terminal Finish Tin (Sn)
Resistance 108mOhm
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Discontinued
JESD-609 Code e3
Size / Dimension 0.748Lx0.197W x 0.520 H 19.00mmx5.00mmx13.20mm
Series TAC ATO?
Packaging Bulk

Physical

Terminal Shape TAB/BLADE
Package / Case Blade, ATO/ATC
Mounting Type Holder
Mount Holder, Socket
