0239007.MXP
RoHS
RoHS compliant
RoHS compliantPackage 5mm x 20mm
Category Circuit Protection / Fuses
Description
FUSE GLASS 7A 125VAC 5X20MM
PDF
/
Buying Options
Total Price: USD $0.92
Unit Price: USD $0.9152
≥1 USD $0.9152
≥10 USD $0.88352
≥100 USD $0.8272
≥500 USD $0.684464
≥1000 USD $0.570328
≥3000 USD $0.556054
Inventory: 1129
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC Unknown
Radiation Hardening No
Dimensions
Diameter 5.2mm
Technical
Fuse Class Supplemental
Trip Time or Delay 14400 s
Fuse Current 7A
Joule Integral-Nom 305 J
Outside Diameter 5.2 mm
Blow Characteristic TIME LAG
Circuit Protection Type ELECTRIC FUSE
DC Cold Resistance 0.0114Ohm
Melting I2t 305.758
Breaking Capacity @ Rated Voltage 10kA
Fuse Type Cartridge, Glass
Response Time Slow Blow
Working Voltage 125V
Approval Agency CE, CSA, KC, PSE, UL
Voltage - Rated AC 125V
Reference Standard CE; CSA; KC; PSE; UL
Current Rating 7A
Voltage - Rated DC 125V
Terminal Finish Nickel (Ni)
Resistance 11.4mOhm
ECCN Code EAR99
Termination Clip
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Size / Dimension 0.205Diax0.787L 5.20mmx20.00mm
Series 239
Packaging Bulk
Operating Temperature -55°C~125°C
Physical
Body Material Glass
Number of Pins 2
Terminal Shape END CAP
Package / Case 5mm x 20mm
Mounting Type Holder
Mount Clip, Holder, Surface Mount
Supply Chain
Factory Lead Time 15 Weeks
