0239.400H
RoHS
/
Package 5mm x 20mm
Category Circuit Protection / Fuses
Description
FUSE GLASS 400MA 250VAC 5X20MM
PDF
/
Inventory: 9206
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Dimensions
Body Height 20mm
Technical
Pre-arcing Rating 1.4 A2/s
Fuse Class Supplemental
Trip Time or Delay 14400 s
Joule Integral-Nom 1 J
Fuse Size 5x20mm
Blow Characteristic TIME LAG
Circuit Protection Type ELECTRIC FUSE
DC Cold Resistance 1.46Ohm
Melting I2t 1.53
Breaking Capacity @ Rated Voltage 35A
Fuse Type Cartridge, Glass
Response Time Slow Blow
Physical Dimension 5.2mm x 20mm
Body Length or Diameter 5.2mm
Approval Agency CSA, K-MARK, METI, UL
Voltage - Rated AC 250V
Reference Standard CE; CSA; KC; UL
Current Rating 400mA
Reach Compliance Code unknown
Terminal Finish Tin (Sn)
Resistance 1.46Ohm
ECCN Code EAR99
Termination Clip
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e3
Size / Dimension 0.205Diax0.787L 5.20mmx20.00mm
Series 239
Packaging Bulk
Operating Temperature -55°C~125°C
Physical
Terminal Shape END CAP
Surface Mount NO
Package / Case 5mm x 20mm
Mounting Type Holder
